Basic Info.
Model NO.
MDK4120D
Speed
2.5 Minutes/Piece (Including Feed in & Feed out)
Transport Package
Wood Case/ Pallet
Specification
2800*2290*2060mm
Trademark
YUTON
Origin
China
HS Code
8465100000
Production Capacity
50 Sets/Month
Product Description
CNC lock hole and hinge slot machine MDK4120D
Function:
Used for processing lock hole and hinge slot on door leaf.
Technical specification:
About Us Used for processing lock hole and hinge slot on door leaf.
1,Auto tool setting;
2,Auto measure thickness;
3,Auto measure width;
4,Auto processing;
5,Auto lubrication;
2,Auto measure thickness;
3,Auto measure width;
4,Auto processing;
5,Auto lubrication;
Technical specification:
| Working length | 1800-2400mm |
| Working width | 600-1100mm |
| Working thickness | 30-80mm (only can do "down open" hinge for 60-80mm thick workpiece) |
| Hinge motor power | 3x0.4Kw |
| Lock-slot motor power | 3.7Kw |
| Lock sidestep motor power | 0.4Kw |
| Lock-hole motor power | 2*1.5Kw |
| Max moving speed of tool | 8m/min |
| Overall size | 2740*2270*1620mm |
| Wooden case size | 2800*2290*2060mm |
| (One 20GP container can load two sets of MDK4120D) | |
| Weight | 1800kg |
| Voltage | 380V, 50HZ, 3phase. |
