Electric Sliding Step with CE Certified for Vans and Minibus

Product Introduction
ES series electric step is kinds of equipment which can help passengers get into vehicles, such as cars,
public bus, taxi, ambulance and so on. This step, with loading capacity of 250 kg, can work steadily,
reliably and safely.
We have different steps with several specifications, which can meet different requirements.
This step has a frame with thickness of only 70mm, and it is also suitable for the low-floor vehicle.
The operation can be electric or manual. Electric operation is done by remote control.
This step has passed the CE certification.

Description:

 Small frames, downy line, smooth platform and easy operation;
 Reduce the floor height to make entrance easy;
 Operated by the driver or attendant;
 Rated voltage is 12V-24V;
 Waterproof connectors;
 It can be controlled through door. If door is closed, this step will stow automatically;
 If there is an obstruction when extending, the step will stop automatically; press switch again to extend it.
 Can be operated fully automatically, that is to say, when door is open, this step will extend; when door is closed, this step will retract
 There is sound and light for warning during working
 There is interlock function, which can interlock with vehicle brake
 Can be stowed for emergency
 Has been tested 100000 cycles
 Test weight is 500kg
Accessory:
 Fully automatic operation: simply swap the switch to change to a fully automatic operation on door.
 Sensitive edge: It will stop automatically if there is obstruction. The operator should press the switch again to extend the step.
 Buzzer: equipment for auto alarm.
 Noise: the noise of the step is below 70dB when working.
Installation:
 The mounting points on the side of step frame are flexible.
 This step can be installed at different place such as door, chassis, or other place of vehicle.
 It is suitable for many kinds of vehicle
 Every step has its own serial number which is easy to track
Details:
